Model: S3R / S6R

Sensor Specifications

* **Type:** Vox Uncooled
* **Resolution, pixels:**
* S3R: 384 × 288
* S6R: 640 × 512
* **Pixel Pitch, µm:** 12
* **NETD, mK:**
* S3R: <25
* S6R: <20
* **Frame Rate, Hz:** 50

—

Optical Specifications

* **Objective Lens, mm:** 35
* **Optical Zoom, x:**
* S3R: 3.5
* S6R: 2
* **Field of view, degrees / yd @ 100 yd:**
* S3R: 7.5° / 13.2 yd
* S6R: 12.5° / 21.9 yd
* **Digital Zoom, x:** 1 to 4
* **Eye Relief, mm:** 48
* **Diopter Adjustment, D:** -5 to +5
* **Detection Range, m/yd:** 1800 / 1969

—

Display Specifications

* **Type:** OLED
* **Resolution, pixels:** 1024 × 768

—

Laser Rangefinding

* **Measuring Range, m/yd:** 1200 m / 1312 yd
* **Measurement Accuracy, m/yd:** ±1 m / ±1.09 yd

—

Wi-Fi

* **Wireless Protocol:** Wi-Fi
* **Frequency:** 2.4 GHz

—

Video Recorder

* **Video / Photo Resolution, pixel:** 1024 × 768
* **Video / Photo Format:** .mp4 / .jpg
* **Built-in Memory:** 32 GB

—

Physical Specifications

* **Degree of Protection:** IP67
* **Operating Temperature Range:** -4 to +122 °F
* **Weight:** 1 lb
* **Dimensions:** 5.3 × 2.7 × 2.2 inch

—

Connections and Compatibilities

* **Battery Type:** 18650
* **Operating Time on Battery Pack (at 72°F):** 4 h
* **External Power Supply:** 5V (Type-C USB)
* **Max Recoil Power on Rifled Weapon (Eo):** 1000 / 6000 g/Joules
* **Compatible Mounts:** Picatinny mount
