| THERMAL PERFORMANCE & IMAGE CLARITY |
|
| Thermal Engine |
6th Generation Thermal Engine |
| Sensor |
High-resolution 640×512 sensor with 12mm pixel pitch and ≤18mK NETD sensitivity with smooth 50 Hz refresh for detailed long-range thermal imagery |
| ATN SharpIR AI Technology |
Real-time AI enhancement improves contrast and edge clarity for confident identification at distance |
| High-Contrast OLED Display |
800×600 OLED display provides crisp visuals and smooth motion tracking for extended use |
| Multiple Color Palettes |
White Hot, Black Hot, Iron Red, Alarm, Green Hot, Sepia |
| OPTICS & DETECTION PERFORMANCE |
|
| 25 mm Germanium Lens |
Narrower field option (17.5deg x 14deg) optimized for maximum detection reach |
| Extended Detection Range |
Up to 1,300 meters of detection capability for long-distance monitoring |
| Smooth and Step Digital Zoom |
Digital zoom up to 8x for flexible magnification control |
| Manual Focus System |
Precise focus tuning from 1 m to infinity for near and far observation |
| TOOLS & TECHNOLOGY |
|
| Hot Point Tracking |
Automatically highlights the hottest object in view to speed up detection and maintain focus |
| Scene Modes |
Optimized thermal performance across different terrains and lighting conditions |
| RECORDING, CONNECTIVITY & STORAGE |
|
| Video, Audio, and Image Recording |
Capture video, audio, and images directly to 32 GB internal memory |
| Built-In Wi-Fi Connectivity |
Wi-Fi hotspot enables live streaming, review, and instant sharing via the ATN Connect 6 app |
| USB Type-C Interface |
Supports charging, data transfer, and external power |
| FIELD-READY DESIGN |
|
| Rugged IP67 Durability |
Waterproof and dustproof housing built for rugged environments |
| Balanced Compact Design |
320 g form factor for comfortable extended use |
| Efficient Power System |
Internal rechargeable battery delivers up to 6.5 hours and supports USB Type-C external power |
| OPTICS & SENSOR |
|
| Detector Type |
12 mm VOx Uncooled Focal Plane Array |
| Sensor Resolution |
640 x 512 |
| Refresh Rate |
50 Hz |
| Thermal Sensitivity (NETD) |
≤ 18 mK |
| SharpIR(c) |
Yes |
| Non-Uniformity Correction (NUC) |
Auto / Semi Auto / Manual |
| Lens System |
25 mm (Ge); F/1.0 |
| Field of View (HxV) |
17.5deg x 14deg |
| Focus Mechanism |
Manual Focus (1 m to infinity) |
| Magnification |
1.75 – 14x |
| Digital Zoom |
1x, 2x, 4x, 8x |
| Detection Range |
1300 m |
| Color Palettes |
White Hot, Black Hot, Iron Red, Alarm, Green Hot, Sepia |
| DISPLAY & VIEWING |
|
| Display Resolution |
800 x 600 OLED Display |
| Diopter Range |
-5 to +5 D |
| Scene Modes |
Yes |
| Hot Point Tracking |
Yes |
| RECORDING & CONNECTIVITY |
|
| Video / Audio Recording |
Yes |
| Image Capture |
Yes |
| Internal Storage Capacity |
32 GB |
| Built-in Wi-Fi (Hotspot) |
Yes |
| Media Output |
USB Type-C |
| App (Apple Store / Google Play) |
Yes (ATN Connect 6 – iOS & Android) |
| POWER SYSTEM |
|
| Battery Type |
Internal Rechargeable |
| Battery Life |
~ 6.5 hrs |
| Supports External Power Supply |
Yes (USB Type-C 5 VDC / 2 A) |
| Standby / Sleep Mode |
Yes |
| DESIGN & DURABILITY |
|
| Weight (with Battery) |
320 g / 0.7 lb |
| Dimensions (LxWxH) |
158 x 57 x 50 mm (6.20 x 2.23 x 1.98 in) |
| Operating Temperature |
-30 degC to 55 degC (-22 degF to 131 degF) |
| Waterproof / IP Rating |
IP67 |
