Pulsar Axion XG30 Compact Thermal Monocular

SKU
PL77508
$1,999.97
Add to Compare
0% APR for 6/12 months or interest bearing for 36 months*

Axion is designed for constant, often hard use. A magnesium alloy housing is light and strong at the same time. The housing reliably protects the internal components of a thermal imaging device from shocks, drops, moisture, heat or cold. At the same time, a metal housing effectively removes the heat from electronics, minimizes image noise and increases consistency of the device operation during long-term observation.



Sensor 640x480 pix. @ 12μm (sNETD < 25 mK)
Objective lens F30/1.2
Magnification, x 2 - 16
Field of view (HxV), degrees 14.6°
Detection range, yds 1400
Sensor Type Uncooled
Resolution, pixels 640x480
Pixel pitch, µm 12
NETD, mK <40
Frame rate, Hz 50
sNETD, mK <25
Objective lens F35/1.0
Magnification, x 2-16x
Field of view (HxV), degrees 14.6
Eye relief, mm N/A
Display Type AMOLED
Display Resolution, pixels 640x400
Detection range, yds 1400
Video / photo resolution, pixel 960x600
Video / photo format .mp4 / .jpg
Built-in memory, GB 64
Wireless Protocol Wi-Fi
Wireless Standard IEEE 802.11 b/g/n/ac (WPA)
Frequency, GHz 2.4 / 5
Degree of protection, IP code IPХ7 (waterproof)
Operating temperature range, °F -13...+104
Mount, type 1/4"
Supported Application Stream Vision 2
Output voltage, V 3.0 – 4.2
Battery type APS3 External
Battery capacity, mAh 3200
Operating time on battery pack 7 hours (at t=22°C)
External power supply, V 5V/9V USB-C
Body material Magnesium alloy
Dimensions, in 5.6 x 1.6 x 2.7
Weight, oz 8.5 (with battery)
SKU (Model #) PL77509





  • Sensivity amplification levels
  • A selection of 8 color palettes
  • Frost-resistant AMOLED display
  • Stream Vision 2 app support for iOS and Adroid
  • Long-life removable battery
  • Fast charging with USB Type-C
  • IPX7 Fully waterproof

High-quality reinforced magnesium alloy housing

Axion is designed for constant, often hard use. A magnesium alloy housing is light and strong at the same time. The housing reliably protects the internal components of a thermal imaging device from shocks, drops, moisture, heat or cold. At the same time, a metal housing effectively removes the heat from electronics, minimizes image noise and increases consistency of the device operation during long-term observation.



 Dual Wi-Fi waveband support 2.4 / 5 GHz


In Axion thermal imagers, the standard smartphone connection frequency range via a 2.4 GHz WiFi channel is complemented with an effective 5 GHz range. The 5 GHz connection offers better bandwidth, a faster data transfer rate, noise immunity and improved connection stability, resulting in more productive and easier operation of the thermal imager with a smartphone.

User Mode

Use the brightness and contrast adjustments to maximise the detail and informative value of the image in specific observation conditions. The User Mode function saves selected brightness and contrast settings in the device's memory providing optimal image quality for the next use of the thermal imager immediately, with no additional adjustments needed.

Fast aperture F35/1.0 lens

Germanium F35/1.0 lens features high infrared transmission in the LWIR range. Due to the high precision manufacturing of the optical elements of the lens, the image generated by the Axion 2 thermal imaging device sensor is distinguished for its clarity and detailing.

Extended battery life. Up to 7 hours on a single charge

A quick-change APS3 rechargeable battery provides 7 hours of continuous operation of the thermal imaging device on a single charge. The battery is removed from a battery housing and replaced with a new one in seconds. The battery is charged in a special device or inside the device from a PC, household power system or power bank via USB. The same sources are used for external power supply of a thermal imaging device.

3 levels of sensitivity amplification

The Axion thermal imaging devices use a new approach to image optimization depending on the purposes and conditions of observation and provide high-quality rendering of both target objects and background. Three levels of signal amplification in combination with a connected smoothing filter and fine brightness and contrast adjustments give the hunter great opportunities for long-range detection of the animal under different weather and temperature conditions and determining its trophy qualities.

Pocket-sized dimensions and light weight

Axion has a space-saving and pocket-sized design and weighing 300 grams. The device is easy to grip and operate by right-handed and left-handed people due to the symmetrical design and in-line buttons arrangement on the upper panel.
