The Symbion LRF DXR50 is an innovative multispectral binocular that combines thermal imaging and digital day and night vision in a single device, offering enhanced detection, detection and identification capabilities. The Symbion LRF DXR50 produces detailed images in different wavelength spectrums (visible, near-infrared and long-wave infrared), making it a truly versatile instrument for observation at any time of day and in all weather conditions. In this way, the Symbion combines the advantages of both technologies: it makes it easier to find an object thanks to the highly sensitive thermal imaging channel and to assess the terrain in the digital night vision channel, as well as the clear identification of all the smallest features and details of the object in the combined picture-in-picture mode of both channels.
Did you know?
Financing options are available at checkout!
Precise Laser Rangefinder with 1600+ Yard RangeEmpty heading
Knowing the exact target distance is key to making informed decisions in the field. The Symbion LRF DXR50’s integrated laser rangefinder, with a range of up to 1,600 yards, enables precise distance measurements with both single measurement and continuous scanning modes, providing fast, reliable situational awareness without guesswork.
New HD 640×480 Thermal SensorEmpty heading
The Symbion LRF DXR50 brings thermal imaging to an entirely new standard. Its stunning 640x480px thermal sensor produces ultra-high-definition images, brimming with fine detail and clarity—perfect for flawless animal identification. Every silhouette, anatomical feature, and subtle movement comes into sharp focus, empowering you to observe wildlife with unparalleled precision.
High Image Detail Across the Entire 4-32x Range
Achieve exceptional image detail throughout the entire 4-32x magnification range. The variable 4-32x zoom enhances focus and delivers outstanding object recognition at extended distances, while the HD sensor preserves high-definition clarity at every level of magnification. Enjoy smooth, customizable zoom control, with options for gradual 2x increments or continuous adjustments, ensuring an ideal field of view and magnification ratio tailored to each unique observation.
Classic Binocular Design
The Smbion LRF DXR50 embodies the timeless look and feel of classic binocular design, combining a compact form with ergonomic excellence. These thermal imaging binoculars fit naturally in your hands, boasting a sleek, attractive exterior that complements their functional design. Eight conveniently placed buttons are effortlessly accessible, allowing instant activation of essential functions with a single touch for an intuitive, seamless user experience.
Extra-Long Detection RangeEmpty heading
The Symbion LRF DXR50’s advanced objective lens, combined with its powerful 640×480 12µm thermal imaging sensor, delivers extraordinary detection performance. Capable of spotting a standard 6-foot-tall object at distances reaching up to 2,500 yards, this device ensures unmatched observation capabilities across vast distances.
| Category | Specification | Value |
|---|---|---|
| Main | Sensor | 640 × 480 @ 12 µm (NETD <35 mK) |
| Objective Lens | 50 mm f/1.0 | |
| Magnification | 4–32x | |
| Field of View (H × V) | 8.8° / 15.4 m @ 100 m | |
| Detection Range | 2,515 yards | |
| Sensor Specifications | Type | Uncooled |
| Resolution | 640 × 480 pixels | |
| Pixel Pitch | 12 µm | |
| NETD | <35 mK | |
| Frame Rate | 50 Hz | |
| Optical Specifications | Objective Lens | 50 mm f/1.0 |
| Magnification | 4–32x | |
| Field of View (H × V) | 8.8° / 15.4 m @ 100 m | |
| Eye Relief | 13 mm | |
| Display Specifications | Type | AMOLED |
| Resolution | 1920 × 1080 pixels | |
| Range Performance | Detection Range | 2,515 yards |
| Laser Rangefinding | Laser Safety Class | Class 1 (IEC 60825-1:2014) |
| Wavelength | 905 nm | |
| Max. Measuring Range | 1,640 yards | |
| Measurement Accuracy | ±1 m | |
| Video Recorder | Video / Photo Resolution | 1920 × 1080 pixels |
| Video / Photo Format | .mp4 / .jpg | |
| Built-in Memory | 64 GB | |
| Wi-Fi | Wireless Protocol | Wi-Fi |
| Wireless Standard | IEEE 802.11 b/g/n/ac | |
| Frequency | 2.4 / 5 GHz | |
| Environmental Characteristics | Degree of Protection | IP67 |
| Operating Temperature Range | -13 to +122 °F | |
| Connections and Compatibilities | Mount Type | 1/4″ socket |
| Supported Applications | Stream Vision 2 / Stream Vision Ballistics | |
| Power Supply | Battery Type | APS5 |
| Operating Time (at 71 °F) | 10 h | |
| External Power Supply | 5V / 9V (USB Type-C Power Delivery) | |
| Weight & Size | Body Material | Magnesium alloy |
| Dimensions | 207 × 132 × 72.5 mm | |
| Weight | 2.2 lb |
